Goodrive3000 series medium voltage inverters
Function
Name
code
deviation limit
Upper limit of
P09.09
PID output
Lower limit of
P09.10
PID output
Feedback offline
P09.11
detection value
Feedback offline
P09.12
detection time
P09.13 PID adjustment
Proportional
gain at low
P09.14
frequency (Kp)
PID command of
P09.15
ACC/DEC time
PID output filter
P09.16
time
P10 Group Simple PLC and multi-step speed control
P10.00 Simple PLC
Simple PLC
P10.01
memory
Detailed instruction of parameters
P09.10~100.0% (Max. frequency or
voltage)
-100.0%~P09.09 (Max. frequency or
voltage)
0.0~100.0%
0.0~3600.0s
0x0000~0x1111
LED ones:
0: Keep the integral adjustment when
the frequency reaches the upper and
lower limit
1: Stop the integral adjustment when
the frequency reaches the upper and
lower limit
LED tens:
0: The same with the setting direction
1:Opposite to the setting direction
LED hundreds:
0: Limit to the maximum frequency
1: Limit to frequency A
LED thousands:
0:A+B frequency, the buffer of A
frequency is invalid
1:A+B frequency, the buffer of A
frequency is valid
ACC/DEC is determined by ACC time
4 of P08.04
0.00~100.00
0.0~1000.0s
0.000~10.000s
0: Stop after running once
1: Run at the final value after running
once
2: Cycle running
0: Power loss without memory
1: Power loss with memory
-183-
Goodrive3000 series converter
Default
Setting range
value
P09.10~100.0 100.0%
-100.0~P09.09 0.0%
0.0~100.0% 0.0%
0.0~3600.0 1.0s
0000~1111 0x0001
0.00~100.00 1.00
0.0~1000.0s 0.0s
0.000~10.000s 0.000s
0~2 0
0~1 0
Modify No.
○
355.
○
356.
○
357.
○
358.
○
359.
○
360.
○
361.
○
362.
○
363.
○
364.
