Function
Name
code
AI2 lower limit
P05.34 corresponding
setting
P05.35 AI2 middle value
AI2 middle value
P05.36 corresponding
setting
P05.37 AI2 upper limit
AI2 upper limit
P05.38 corresponding
setting
AI2 input filtering
P05.39
time
P05.40 AI3 lower limit
AI3 lower limit
P05.41 corresponding
setting
P05.42 AI3 upper limit
AI3 upper limit
P05.43 corresponding
setting
AI3 input filtering
P05.44
time
The above function codes define the relationship between the analog input voltage and its corresponding
setting. When the analog input voltage goes beyond the range between the set upper limit and lower limit,
it will be calculated with the upper limit or lower limit.
When the analog input is current input, 0mA~20mA current corresponds to 0V~10V voltage.
In different applications, 100.0% of the analog setting corresponds to different nominal values. Please
refer to the descriptions of each application section for details. The following figure illustrates the cases of
several settings:
Input filtering time: adjust the sensitivity of analog input. Increasing this parameter properly can avoid
malfunction caused by interfered analog input but may reduce the sensitivity of analog input.
Note: AI1 and AI3 can support 0~10V/0~20mA input and when AI1 and AI3 selects 0~20mA input,
the corresponding voltage of 20mA is 10V; AI2 supports -10~+10V input.
Detailed parameter description
-100.0%~100.0%
P05.33~P05.37
-100.0%~100.0%
P05.35~10.00V
-100.0%~100.0%
0.000s~10.000s
0.00V~P05.42
-100.0%~100.0%
P05.40~10.00V
-100.0%~100.0%
0.000s~10.000s
Corresponding
setting
100.0%
-10V
-20mA
-100.0%
-28-
Goodrive3000 series PWM rectifier
Setting range
-100.0%~100.0%
P05.33~P05.37
-100.0%~100.0%
P05.35~10.00V
-100.0%~100.0%
0.000s~10.000s
0.00V~P05.42
-100.0~100.0%
P05.40~10.00V
-100.0~100.0%
0.000s~10.000s
AI
10V
20mA
Default
0.0%
0.00V
0.0%
10.00V
100.0%
0.100s
0.00V
0.0%
10.00V
100.0%
0.100s
