INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 116

Goodrive3000 series medium voltage inverters
Function
Name
code
Action when the
P08.47 frequency setting is
at power off
The function code is the way to deal with set frequency at power off.
Function
Name
code
Magnetic flux
P08.50
braking
This function code is used to enable magnetic flux braking.
0: Invalid
100~150: The larger the coefficient is, the stronger the braking is.
This inverter can slow down the motor by increasing the magnetic flux. In this way, the energy generated
by the motor during braking can be transformed into heat energy.
The inverter monitors the state of the motor continuously even during the magnetic flux braking period.
So the magnetic flux braking can be used in the motor stop, as well as to change the rotating speed of the
motor. The other advantages are:
Brake immediately after the stop command. It does not need to wait until the magnetic flux weakens.
The cooling effect becomes better. The current of the stator other than that of the rotor increases during
magnetic flux braking, while the cooling of the stator is more effective than the cooling of the rotor.
Function
Name
code
Input power factor of
P08.51
the inverter
Adjust the displayed current value of the input side of the inverter at AC input.
Note: The function is not applicable at DC input.
Detailed instruction of parameters
0x000~0x111
LED ones: Action selection when the
digital adjusting frequency is at power
off
0: Save when the power is off
1: Clear when the power is off
LED tens: Action selection when
MODBUS setting frequency is at
power off
0: Save when the power is off
1: Clear when the power is off
LED hundreds: Action selection when
other communication setting
frequency is at power off
0: Save when the power is off
1: Clear when the power is off
Detailed instruction of parameters
0: Invalid
100~150
Detailed instruction of parameters
0.00~1.00
-115-
Goodrive3000 series converter
Default
Setting range
value
0x000~0x111 0x000
Default
Setting range
value
0~150
Default
Setting range
value
0.00~1.00
0
0.56
