INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 161

Goodrive3000 series medium voltage inverters
Function
Name
code
Motor 1 overload
protection
P02.27
coefficient
Motor 1 power
P02.28 correction
coefficient
Motor 1
parameter
P02.29
display
P03 Group Vector control
Speed loop
P03.00 proportional gain
1
Speed loop
P03.01
integral time 1
Switching low
P03.02
frequency
Speed loop
P03.03 proportional gain
2
Speed loop
P03.04
integral time 2
Switching high
P03.05
frequency
Speed loop
P03.06
output filter
Vector control
slip
P03.07 compensation
coefficient
(Electromotion)
Vector control
slip
compensation
P03.08
coefficient
(Power
generation)
Current loop
P03.09 proportional
coefficient P
P03.10 Current loop
Detailed instruction of parameters
compensation)
2: Frequency conversion motor
(without low speed compensation)
20.0%~120.0%
0.00~3.00
0: Display according to motor type
1: Display all parameters
0~200.0
0.000~10.000s
0.00Hz~P03.05
0~200.0
0.001~10.000s
P03.02~P00.03(Max. frequency)
0~8 (corresponding to 0~2^8/10ms)
50~200%
50~200%
0~65535
0~65535
-160-
Goodrive3000 series converter
Default
Setting range
value
20.0~120.0 100.0%
0.00~3.00 1.00
0~1 0
0~200.0 20.0
0.000~10.000 1.000s
0.00~P03.05 5.00Hz
0~200.0 20.0
0.000~10.000 1.000s
P03.02~P00.03 10.00Hz
0~8 0
50~200 100%
50~200 100%
0~65535 1000
0~65535 1000
Modify No.
○
72.
○
73.
○
74.
○
75.
○
76.
○
77.
○
78.
○
79.
○
80.
○
81.
○
82.
○
83.
○
84.
○
85.
