INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 85

Goodrive3000 series medium voltage inverters
Function
Name
code
Motor 2 oscillation
P04.25
control threshold
The function codes define the setting way of Goodrive3000 series motor 2 to meet different requirements
of load features. See specific information in P04.13~P04.25.
Note: P04 group includes V/F parameters of four motors which can be displayed simultaneously
and will be valid to the selected motor. The motor can be selected by the channels defined in the
function code P08.31.
Function
Name
code
Energy-saving
P04.26
operation
The motor will automatically adjust the output voltage under light load to save energy.
Function
Name
code
Voltage setting
P04.27
channel
Select the output voltage setting channel at V/F curve separation.
Note: 100% corresponds to motor rated voltage.
Note: 3, 4, 8 and 9 need to use extension cards.
Function
Name
code
Keypad setting
P04.28
voltage
The function code is the voltage digital set value when the voltage setting channel is selected as "keypad
setting" (P04.27=0).
Function
Name
code
Voltage increasing
P04.29
time
Detailed instruction of parameters
0.00Hz~P00.03(Max. frequency)
Detailed instruction of parameters
0: No action
1: Automatic energy-saving
operation
Detailed instruction of parameters
0: Keypad setting (Determined by
P04.28)
1: AI1 setting
2: AI2 setting
3: AI3 setting
4: HDI pulse setting
5: Multi-step setting (Determined by
the multi-step speed parameter of
P10)
6: PID setting
7: MODBUS communication setting
8: PROFIBUS/CANopen
communication setting
9: Ethernet communication setting
10: Reserved
Detailed instruction of parameters
0.0%~100.0% (Motor rated voltage)
Detailed instruction of parameters
0.0~3600.0s
-84-
Goodrive3000 series converter
Default
Setting range
value
0.00~P00.03 30.00Hz
Default
Setting range
value
0~1
Default
Setting range
value
0~10
Default
Setting range
value
0.0~100.0 100.0%
Default
Setting range
value
0.0~3600.0
0
0
5.0s
