INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 170

Goodrive3000 series medium voltage inverters
Function
Name
code
P05.48 AI3 upper limit P05.46~10.00V
Corresponding
P05.49 setting of AI3
upper limit
AI3 input filter
P05.50
time
HDI pulse input
P05.51
function
HDI lower-limit
P05.52
frequency
Corresponding
setting of HDI
P05.53
lower-limit
frequency
HDI upper-limit
P05.54
frequency
Corresponding
setting of HDI
P05.55
upper-limit
frequency
Input filter time
P05.56 of HDI pulse
frequency
P06 Group Output terminals
P06.00 HDO output type
Y1 output
P06.01
P06.02 HDO output
Relay RO1
P06.03
output
Relay RO2
P06.04
output
Detailed instruction of parameters
-100.0%~100.0%
0.000s~10.000s
0: Frequency setting input
1~2: Reserved
0.00kHz~P05.54
-100.0%~100.0%
P05.52~50.00kHz
-100.0%~100.0%
0.000s~10.000s
0: Open collector output
1: Reserved
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: Inverter fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-excitation
14: Overload pre-alarm
15: Underload pre-alarm
-169-
Goodrive3000 series converter
Default
Setting range
value
P05.46~10.00 10.00V
-100.0~100.0 100.0%
0.000~10.000 0.100s
0~2 0
0.00~P05.54 0.00KHz
-100.0~100.0 0.0%
50.00KH
P05.52~50.00
z
-100.0~100.0 100.0%
0.000~10.000 0.100s
0~1 0
0~30 0
0~30 0
0~30 1
0~30 5
Modify No.
○
189.
○
190.
○
191.
◎
192.
○
193.
○
194.
○
195.
○
196.
○
197.
◎
198.
○
199.
○
200.
○
201.
○
202.
