Goodrive3000 series medium voltage inverters
Function
Name
code
Keypad setting
P04.28
voltage
Voltage
P04.29
increasing time
Voltage
P04.30
decreasing time
Max. output
P04.31
voltage
Min output
P04.32
voltage
P04.33 Reserved
P04.34 Reserved
P04.35 Reserved
P05 Group Input terminals
P05.00 HDI input type
S1 terminal
P05.01
function
S2 terminal
P05.02
function
S3 terminal
P05.03
function
S4 terminal
P05.04
function
S5 terminal
P05.05
function
S6 terminal
P05.06
function
S7 terminal
P05.07
function
S8 terminal
P05.08
function
HDI terminal
P05.09
function
Detailed instruction of parameters
9: Ethernet communication setting
10: Reserved
0.0%~100.0% (Motor rated voltage)
0.0~3600.0s
0.0~3600.0s
P04.32~100.0% (Motor rated voltage)
0.0%~ P04.31 (Motor rated voltage)
0: HDI is pulse input.
1: HDI is switch input.
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward rotation jogging
5: Reverse rotation jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting
(DOWN)
12: Cancel the frequency change
setting
13: Shift between A setting and B
setting
14: Shift between combination setting
and A setting
15: Shift between combination setting
and B setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Multi- step speed pause
-165-
Goodrive3000 series converter
Default
Setting range
value
0.0~100.0 100.0%
0.0~3600.0 5.0s
0.0~3600.0 5.0s
0.0~100.0 100.0%
0.0~100.0 0.0%
0~1 0
0~63 1
0~63 4
0~63 7
0~63 0
0~63 0
0~63 0
0~63 0
0~63 0
0~63 0
Modify No.
○
133.
○
134.
○
135.
◎
136.
◎
137.
●
138.
●
139.
●
140.
◎
141.
◎
142.
◎
143.
◎
144.
◎
145.
◎
146.
◎
147.
◎
148.
◎
149.
◎
150.
