Goodrive3000 series medium voltage inverters
Function
Name
code
function
selection
QUICK shifting
sequence of
P07.03 running
command
channel
STOP/RST stop
P07.04
function
Parameter
selection 1 at
P07.05
running state
Parameter
selection 2 at
P07.06
running state
Detailed instruction of parameters
1: Jogging running
2: Shift the display state by the shifting
key
3: Shift between forward rotation and
reverse rotation
4: Clear UP/DOWN setting
5: Coast to stop
6: Shift the running command sources
in sequence
7: Quick commission mode (according
to the non-factory parameter
commissioning)
0: Keypad control→terminal control→
communication control
1: Keypad control←→terminal control
2: Keypad control←→communication
control
3: Terminal control←→
communication control
0: Only valid for keypad control
1: Both valid for keypad and terminal
control
2: Both valid for keypad and
communication control
3: Valid for all control modes
BIT0: Running frequency (Hz on)
BIT1: Set frequency (Hz flickering)
BIT2: Bus voltage (V on)
BIT3: Output voltage(V on)
BIT4: Output current(A on)
BIT5: Running rotating speed (rpm
on)
BIT6: Output power(% on)
BIT7: Output torque(% on)
BIT8: PID reference(% flickering)
BIT9: PID feedback(% on)
BIT10: Input terminal state
BIT11: Output terminal state
BIT12: Torque set value(% on)
BIT13: Pulse count value
BIT14: Reserved
BIT15: PLC and current step in
multi-step speed
BIT0: AI1 value (V on)
BIT1: AI2 value (V on)
BIT2: AI3 value (V on)
BIT3: HDI frequency
-173-
Goodrive3000 series converter
Default
Setting range
value
0~3 0
0~3 0
0~FFFF 0x03FF
0000~FFFF 0x0000
Modify No.
○
240.
○
241.
○
242.
243.
