Goodrive3000 series medium voltage inverters
P15 Group PROFIBUS function
Function
Name
code
P15.00 Module type
Select the communication protocol.
Function
Name
code
PROFIBUS/CANopen
P15.01
module address
The function code is used to identify the address of the inverter during serial communication.
Note: 0 is the broadcast address only for receiving and carrying out broadcast command of upper
computer rather than response.
Function
Name
code
PZD2 receiving
P15.02
PZD3 receiving
P15.03
P15.04 PZD4 receiving
PZD5 receiving
P15.05
PZD6 receiving
P15.06
PZD7 receiving
P15.07
P15.08 PZD8 receiving
P15.09 PZD9 receiving
PZD10 receiving
P15.10
PZD11 receiving
P15.11
PZD12 receiving
P15.12
For the second PZD in PROFIBUS-DP communication and master communication (receiving), see
detailed information as follows:
Function
Name
code
Invalid
0
Set frequency
1
2 PID reference
3 PID feedback
Torque set value
4
Set value of forward
5 rotation upper-limit
frequency
Set value of reverse
6
rotation upper-limit
Detailed parameter description
0: PROFIBUS
Detailed parameter description
0~127
Detailed parameter description
0: Invalid
1: Set frequency
2: PID reference
3: PID feedback
4: Torque set value
5: Set value of forward rotation
upper-limit frequency
6: Set value of reverse rotation
upper-limit frequency
7: Electromotion torque upper limit
8: Braking torque upper limit
9: Virtual input terminal command
10: Virtual output terminal command
11: Voltage set value (special for V/F
separation)
12: AO output set value 1
13: AO output set value 2
0~Fmax (Unit: 0.01Hz)
Range (0~1000, 1000 corresponds to 100.0%)
Range (0~1000, 1000 corresponds to 100.0%)
Range (-3000~3000, 1000 corresponds to 100.0% of motor rated
current)
0~Fmax (Unit: 0.01Hz)
0~Fmax (Unit: 0.01Hz)
-132-
Goodrive3000 series converter
Setting range
0~1
Setting range
0~127
Setting range
0~20
0~20
0~20
0~20
0~20
0~20
0~20
0~20
0~20
0~20
0~20
Illustration
Default
0
Default
2
Default
0
0
0
0
0
0
0
0
0
0
0
