Goodrive3000 series medium voltage inverters
P03 Group Control parameters
Function
Name
code
Positive limit
P03.06 amplitude of active
current (rectification)
Negative limit
P03.07 amplitude of active
current (feedback)
Positive limit
P03.08 amplitude of reactive
current (rectification)
Negative limit
P03.09 amplitude of reactive
current (feedback)
Maximum current
P03.10
setting
P03.06 is the Max. active current at rectification output.
P03.07 is the Max. active current at energy feedback.
P03.08 is the Max. reactive current at rectification output.
P03.09 is the Max. reactive current at energy feedback.
The rectifier has automatic current limiting function, which will limit current output no more than P03.10.
Function
Name
code
Voltage loop
P03.11 proportional
coefficient 1
Voltage loop integral
P03.12
coefficient 1
Voltage loop
P03.13 proportional
coefficient 2
Voltage loop integral
P03.14
coefficient 2
Switching voltage of
P03.15
PI parameters
The absolute value of the difference between the setting value and feedback value of DC voltage is ∆.
When ∆ is less than P03.15, it will apply PI parameter 1; when ∆ is more than (or equal to) P03.15, it will
apply PI parameter 2.
Function
Name
code
Bus voltage filter
P03.16
coefficient
P03.16 is displayed on the keypad.
Detailed parameter description
0.0~200.0% (rated current of the
rectifier)
0.0~200.0% (rated current of the
rectifier)
0.0~200.0% (rated current of the
rectifier)
0.0~200.0% (rated current of the
rectifier)
0~250.0% (rated current of the
rectifier)
Detailed parameter description
0.001~30.000
0.01~300.00
0.001~30.000
0.01~300.00
0.01~30.00V
Detailed parameter description
0~1.000s
-24-
Goodrive3000 series PWM rectifier
Setting range
0.0~200.0%
0.0~200.0%
0.0~200.0%
0.0~200.0%
0.0~250.0%
Setting range
0.001~30.000
0.01~300.00
0.001~30.000
0.01~300.00
0.01~30.00
Setting range
0~1.000s
Default
150.0%
150.0%
150.0%
150.0%
200.0%
Default
2.000
20.00
5.500
10.00
10.00V
Default
0.000s
