Goodrive3000 series medium voltage inverters
P16 Group Ethernet function
Function
Name
code
Ethernet
P16.00
communication
speed setting
The function code is used for Ethernet communication speed setting. Generally, select the default value.
Function
Name
code
P16.01
IP address 1
P16.02
IP address 2
P16.03
IP address 3
P16.04
IP address 4
P16.05
Subnet mask 1
P16.06
Subnet mask 2
P16.07
Subnet mask 3
P16.08
Subnet mask 4
The function codes are used to set the IP addresses and subnet masks for Ethernet communication.
IP address format: P16.01. P16.02. P16.03. P16.04
For example: IP address is 192.168.0.1.
Subnet mask format: P16.05. P16.06. P16.07. P16.08
For example: Subnet mask is 255.255.255.0.
Function
Name
code
P16.09
Gateway 1
P16.10
Gateway 2
P16.11
Gateway 3
P16.12
Gateway 4
Set the gateway for Ethernet communication.
Detailed parameter description
0: Self-adapting
1: 100M full-duplex
2: 100M half-duplex
3: 10M full-duplex
4: 10M half-duplex
Detailed parameter description
0~255
0~255
0~255
0~255
0~255
0~255
0~255
0~255
Detailed parameter description
0~255
0~255
0~255
0~255
-136-
Goodrive3000 series converter
Setting range
Default
0~4
Setting range
Default
0~255
0~255
0~255
0~255
0~255
0~255
0~255
0~255
Setting range
Default
0~255
0~255
0~255
0~255
3
192
168
0
1
255
255
255
0
192
168
1
1
