INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 164

Goodrive3000 series medium voltage inverters
Function
Name
code
Motor 1 torque
P04.02
boost close
Motor 1 V/F
P04.03 frequency point
1
Motor 1 V/F
P04.04
voltage point 1
Motor 1 V/F
P04.05 frequency point
2
Motor 1 V/F
P04.06
voltage point 2
Motor 1 V/F
P04.07 frequency point
3
Motor 1 V/F
P04.08
voltage point 3
Motor 1 V/F slip
P04.09 compensation
gain
Motor 1 low
frequency
P04.10
oscillation
control factor
Motor 1 high
frequency
P04.11
oscillation
control factor
Motor 1
P04.12 oscillation
control threshold
Motor 2 V/F
P04.13
curve setting
Motor 2 V/F
P04.14
torque boost
Motor 2 V/F
P04.15 torque boost
close
P04.16 Motor 2 V/F
Detailed instruction of parameters
0.0%~50.0% (Relative to motor 1
rated frequency )
0.00Hz~P04.05
0.0%~110.0% (Rated voltage of motor
1)
P04.03~ P04.07
0.0%~110.0% (Rated voltage of motor
1)
P04.05~P02.02 (Rated frequency of
motor 1)/ P04.05~P02.16 (Rated
frequency of motor 1)
0.0%~110.0% (Rated voltage of motor
1)
0.0~200.0%
0~100
0~100
0.00Hz~P00.03 (Max. frequency)
0: Straight line V/F curve
1: Multi-dot V/F curve
th
2: 1.3 power low torque V/F curve
th
3: 1.7 power low torque V/F curve
th
4: 2.0 power low torque V/F curve
5: Customized V/F(V/F separation)
0.0%: (Automatic) 0.1%~10.0%
0.0%~50.0% (Relative to rated
frequency of motor 2)
0.00Hz~ P04.18
-163-
Goodrive3000 series converter
Default
Setting range
value
0.0~50.0 20.0%
0.00~P04.05 0.00Hz
0.0~110.0 00.0%
P04.03~P04.07 00.00Hz
0.0~110.0 00.0%
P04.05~电机1额
00.00Hz
定频率
0.0~110.0 00.0%
0.0~200.0 100.0%
0~100 10
0~100 10
30.00
0.00Hz~P00.03
Hz
0~5 0
0.0~10.0 0.0%
0.0~50.0 20.0%
0.00~P04.18 0.00Hz
Modify No.
○
107.
○
108.
○
109.
○
110.
○
111.
○
112.
○
113.
○
114.
○
115.
○
116.
○
117.
◎
118.
○
119.
○
120.
○
121.
