Ratings - INVT Goodrive3000 GD3000-01-055G-12 Operation Manual

Goodrive3000 series medium voltage inverters
Function
Motor
overtemperature
protection
Overload protection
Overvoltage
protection
Undervoltage
protection
Important
protection Overcurrent
function protection
Overheat protection
Overvoltage stalling
protection
Overcurrent stalling
protection
Short circuit
protection

2.4 Ratings

2.4.1 Goodrive3000 two-quadrant inverter
Table 2-5 Ratings of Goodrive3000 two-quadrant inverter
Model
GD3000-01-055G-12
GD3000-01-075G-12
GD3000-01-090G-12
GD3000-01-110G-12
GD3000-01-132G-12
GD3000-01-160G-12
GD3000-01-200G-12
GD3000-01-250G-12
GD3000-01-315G-12
GD3000-01-400G-12
GD3000-01-500G-12
GD3000-01-630G-12
GD3000-01-800G-12
GD3000-01-1000G-12
control, switch between torque and speed control mode, etc.
Can connect PT100 externally
150% of rated current: 60s, 180% of rated current: 10s
When the bus voltage above set overvoltage, report overvoltage
When the bus voltage below set undervoltage, report undervoltage
Protect instantly at 220% of rated current, including ACC, DEC and
constant speed overcurrent
IGBT module temperature detection protection
ACC, DEC and constant speed running protection, can set separately
ACC, DEC and constant speed running protection, can set separately
Short circuit protection in output phases and grounding short circuit
protection
Rated power (kW) Rated input current (A) Rated output current (A)
55
75
90
110
132
160
200
250
315
400
500
630
800
1000
-9-
Product overview
Specification
34
47
56
68
82
98
122
150
185
235
300
380
480
600
36
50
60
73
85
104
128
160
195
250
310
395
500
620
