Goodrive3000 series medium voltage inverters
0: No function
1: Jogging running: Press QUICK/JOG to begin the jogging running.
2: Shift the display state by the shifting key: Press QUICK/JOG to shift the displayed function code from
right to left.
3: Shift between forward rotation and reverse rotation: Press QUICK/JOG to shift the direction of the
frequency commands. This function is only valid in the keypad command channels.
4: Clear UP/DOWN setting: Press QUICK/JOG to clear the set values of UP/DOWN.
5: Coast to stop: Press QUICK/JOG to coast to stop.
6: Shift the running command sources in sequence: Press QUICK/JOG to shift the running command
sources in sequence.
7: Quick commission mode (According to the non-factory parameter commissioning)
Note: When QUICK/JOG is used to shift between forward rotation and reverse rotation, the
inverter does not record the state after shifting during power off. The inverter will run according
to the running direction set by P00.13 during next power on.
Function
Name
code
QUICK shifting
P07.03 sequence of running
command channel
When P07.02=6, set the shifting sequence of running command channel.
Function
Name
code
STOP/RST stop
P07.04
function
Select the stop function by STOP/RST. STOP/RST is effective in any state for the fault reset.
Function
Name
code
Parameter selection
P07.05
1 at running state
Detailed instruction of parameters
0: Keypad control→terminal control
→communication control
1: Keypad control←→terminal
control
2: Keypad control←→communication
control
3: Terminal control←→
communication control
Detailed instruction of parameters
0: Only valid for keypad control
1: Both valid for keypad and terminal
control
2: Both valid for keypad and
communication control
3: Valid for all control modes
Detailed instruction of parameters
BIT0: Running frequency (Hz on)
BIT1: Set frequency (Hz flickering)
BIT2: Bus voltage (V on)
BIT3: Output voltage(V on)
BIT4: Output current(A on)
BIT5: Running rotating speed (rpm
on)
BIT6: Output power(% on)
BIT7: Output torque(% on)
BIT8: PID reference(% flickering)
BIT9: PID feedback(% on)
BIT10: Input terminal state
BIT11: Output terminal state
-103-
Goodrive3000 series converter
Default
Setting range
value
0~3
Default
Setting range
value
0~3
Default
Setting range
value
0x0000~0xFFFF 0x03FF
0
0
