INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 121

Goodrive3000 series medium voltage inverters
P10 Group Simple PLC and multi-step speed control
Function
Name
code
P10.00 Simple PLC
Set the simple PLC running mode.
0: Stop after running once: it is necessary to give the inverter the running command again after it finishes
a single cycle and automatically stops.
1: Run at the final value after running once: the inverter automatically keeps the running frequency and
direction of the last step after finishing a single cycle.
2: Cycle running: the inverter automatically enters into next cycle after finishing a single cycle and the
system will not stop until there is a stop command.
Function
Name
code
P10.01 Simple PLC memory
Set simple PLC memory manners when power loss.
0: Power loss without memory
1: Power loss with memory: PLC will memorize the running step and frequency when power loss.
Function
Name
code
P10.02 Multi-step speed 0
Running time of step
P10.03
0
P10.04 Multi-step speed 1
Running time of step
P10.05
1
P10.06 Multi-step speed 2
Running time of step
P10.07
2
P10.08 Multi-step speed 3
Running time of step
P10.09
3
P10.10 Multi-step speed 4
Running time of step
P10.11
4
P10.12 Multi-step speed 5
Running time of step
P10.13
5
P10.14 Multi-step speed 6
Running time of step
P10.15
6
P10.16 Multi-step speed 7
P10.17 Running time of step 0.0~6553.5s (min)
Detailed instruction of parameters
0: Stop after running once
1: Run at the final value after running
once
2: Cycle running
Detailed instruction of parameters
0: Power loss without memory
1: Power loss with memory
Detailed instruction of parameters
-100.0~100.0%
0.0~6553.5s (min)
-100.0~100.0%
0.0~6553.5s (min)
-100.0~100.0%
0.0~6553.5s (min)
-100.0~100.0%
0.0~6553.5s (min)
-100.0~100.0%
0.0~6553.5s (min)
-100.0~100.0%
0.0~6553.5s (min)
-100.0~100.0%
0.0~6553.5s (min)
-100.0~100.0%
-120-
Goodrive3000 series converter
Default
Setting range
value
0~2
Default
Setting range
value
0~1
Default
Setting range
value
-100.0~100.0 0.0%
0.0~6553.5
-100.0~100.0 0.0%
0.0~6553.5
-100.0~100.0 0.0%
0.0~6553.5
-100.0~100.0 0.0%
0.0~6553.5
-100.0~100.0 0.0%
0.0~6553.5
-100.0~100.0 0.0%
0.0~6553.5
-100.0~100.0 0.0%
0.0~6553.5
-100.0~100.0 0.0%
0.0~6553.5
0
0
0.0s
0.0s
0.0s
0.0s
0.0s
0.0s
0.0s
0.0s
