Goodrive3000 series medium voltage inverters
Function
Name
code
Waiting time before
P01.10
DC braking
P01.11 DC braking current 0.0~100.0% (Motor rated current)
P01.12 DC braking time
Starting frequency of DC braking: start the DC braking when running frequency reaches the starting
frequency during stop.
Waiting time before DC braking: the inverter blocks the output before starting DC braking. Start the DC
braking after the waiting time to prevent overcurrent fault caused by DC braking at high speed.
DC braking current refers to the added DC braking. The higher the current, the greater the braking effect.
DC braking time refers to the retention time of DC braking. If the time is 0, DC braking is invalid and the
inverter will stop at the set deceleration time.
Function
Name
code
Dead time of
P01.13
FWD/REV rotation
Shifting between
P01.14
FWD/REV rotation
Set the shifting between FWD/REV rotation of the inverter.
Set the transient time by P01.13 during the process of switching FWD/REV rotation, which is shown in
following figure:
Function
Name
code
P01.15 Stop speed
Detection of stop
P01.16
speed
Detailed instruction of parameters
0.0~50.0s
0.0~50.0s
Detailed instruction of parameters
0.0~3600.0s
0: Switch after 0 frequency
1: Switch after starting frequency
2: Switch after delay at stop speed
(Reserved)
Detailed instruction of parameters
0.00~100.00Hz
0: Speed set value (delay without
stopping)
-70-
Goodrive3000 series converter
Default
Setting range
value
0.0~50.0
0.0~100.0 0.0%
0.0~50.0
Default
Setting range
value
0.0~3600.0
0~2
Default
Setting range
value
0.00~100.00 0.50 Hz
0~1
0.0s
0.0s
0.0s
0
1
