INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 196

Goodrive3000 series medium voltage inverters
Function
Name
code
Motor
P19.01 temperature
pre-alarm point
Motor
P19.02 overtemperature
fault point
Motor
P19.03 overtemperature
action
Starting
temperature of
P19.04 motor
temperature
compensation
Motor
temperature
P19.05
compensation
coefficient
P19.06 Reserved
P19.07 Reserved
P19.08 Reserved
P19.09 Reserved
P20 Group Encoders
P20.00 Encoder type
Encoder pulse
P20.01
number
Encoder
P20.02
direction
Encoder offline
P20.03
detection time
Encoder reverse
P20.04
detection time
Encoder
P20.05 detection filter
times
Detailed instruction of parameters
4: Reserved
0° ~200°
0° ~200°
0: Alarm fault and coast to stop
1: No alarm and keep running
2: No alarm and stop
0~60.0℃
0.0~200.0%
0: Increment encoder
1: Reserved
2: Rotary encoder
3: Reserved
0~60000
LED ones: AB direction
0: Forward
1: Reverse
LED tens: Z pulse direction
0: Forward
1: Reverse
0.0~100.0s
0.0~100.0s
Ones: Low-speed filter times
Tens: High-speed filter times
-195-
Goodrive3000 series converter
Default
Setting range
value
0~200.0 125.0°
0~200.0 150.0°
0~2 0
0~60.0 40.0℃
0.0~200.0 100.0%
0~3 0
0~60000 1024
0~0x11 0x00
0~100.0 0.5s
0~100.0 0.8s
0~0x99 0x23
Modify No.
○
564.
○
565.
○
566.
○
567.
○
568.
●
569.
●
570.
●
571.
●
572.
◎
573.
◎
574.
◎
575.
○
576.
○
577.
○
578.
