INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 55

Goodrive3000 series medium voltage inverters
Function
Name
code
AO2 output
P06.22 Upper output limit 2 P06.20~100.0%
Upper limit
P06.23
corresponding
AO2 output
AO2 output
P06.24
filtering time
P07 Group Human-machine interface
P07.00 User password
P07.01
Parameters copy
QUICK/JOG
P07.02
function selection
P07.03
Reserved
STOP/RST
P07.04
function selection
Parameter display
P07.05
selection in
rectification state
Detailed parameter
description
-10.00V~10.00V
0.000~10.000s
0~65535
0: No operation
1: Upload parameters to the
keypad
2: Download parameters to
the local
0:No function
1: Press QUICK/JOG to
switch the displayed function
code
2: Reserved
3: Quick debugging
0: Valid when keypad control
1: Valid when keypad and
terminal control
2: Valid when keypad and
communication control
3: Always valid
0x0000~0xFFFF
BIT0: DC bus voltage (V)
BIT1: Grid frequency (Hz)
BIT2: Input voltage (V)
BIT3: Input current (A)
BIT4: Input power factor
BIT5: Active current
component (%)
BIT6: Reactive current
component (%)(% light
flickering)
BIT7: Input terminal state
BIT8: Output terminal state
BIT9: AI1 (V)
BIT10: AI2 (V)(V light
flickering)
-54-
Goodrive3000 series PWM rectifier
Setting
Default Modify No.
range
P06.20~100.0% 100.0%
-10.0V~10.00V 10.00V
0.000~10.000s 0.000s
0~65535 0
0~2 0
0~3 0
0~3 3
0~0xFFFF 0x000F
○
115.
○
116.
○
117.
○
118.
◎
119.
○
120.
●
121.
○
122.
○
123.
