INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 66

Goodrive3000 series medium voltage inverters
0: Max. output frequency: 100% of B frequency setting corresponds to Max. output frequency.
1: A frequency command: 100% of B frequency setting corresponds to Max. output frequency. If it is
necessary to adjust on basis of A frequency command, select this setting.
Function
Name
code
Setting source
P00.09
combination
Select setting source combination.
0: A, the current frequency is set to A frequency command.
1: B, the current frequency is set to B frequency command.
2: A+B, the current frequency is set to A+B frequency command.
3: A-B, the current frequency is set to A-B frequency command.
4: Max (A, B): Take the larger value between A and B frequency commands as the set frequency.
5: Min (A, B): Take the smaller value between A and B frequency commands as the set frequency.
Note: The combination can be shifted by terminal functions (P05).
Function
Name
code
Keypad set
P00.10
frequency
When A and B frequency commands are selected as "keypad setting", the function code value is the
initial value of the inverter frequency.
Note: A and B frequency can not be set to the same frequency reference mode.
Function
Name
code
P00.11 ACC time1
P00.12 DEC time1
ACC time refers to the time that the inverter needs to accelerate from 0Hz to Max. output frequency
(P00.03).
DEC time refers to the time that the inverter needs to decelerate from Max. output frequency (P00.03) to
0Hz.
Goodrive3000 series inverters totally define four groups of ACC/DEC time which can be selected via
input terminals (P05). The default value of ACC/DEC time is the first group.
Function
Name
code
P00.13 Running direction
0: Run in default direction: the inverter runs in forward direction. FWD/REV LED is off.
1: Run in opposite direction: the inverter runs in reverse direction. FWD/REV LED is on.
The rotation direction of the motor can be shifted by changing the function code. The effect is equivalent
to the switchover of the rotation directions by adjusting arbitrary two motor lines (U, V and W). When the
Detailed instruction of parameters
0: A
1: B
2: (A+B)
3: (A-B)
4: Max(A, B)
5: Min(A, B)
Detailed instruction of parameters
0.00Hz~P00.03 (Max. frequency)
Detailed instruction of parameters
0.0~3600.0s
0.0~3600.0s
Detailed instruction of parameters
0: Run in default direction
1: Run in opposite direction
2: Forbid reverse running
-65-
Goodrive3000 series converter
Default
Setting range
value
0~5
Default
Setting range
value
0.00~P00.03 50.00Hz
Default
Setting range
value
Depend
0.0~3600.0
on model
Depend
0.0~3600.0
on model
Default
Setting range
value
0~2
0
0
