Goodrive3000 series medium voltage inverters
P05 Group Input terminals
Function
Name
code
Polarity selection of
P05.01
digital input terminals
Set the polarity of digital input terminals
If set the bit as 0, the input terminal is positive, and when set the bit as 1, the input terminal is negative.
BIT3
S4
Function
Name
code
Digital input filtering
P05.03
time
Set the filtering time for S1~S4 terminal sampling. In the case of strong interference, this parameter
should be increased to avoid malfunction.
Function
Name
code
S1 terminal function
P05.04
selection
S2 terminal function
P05.05
selection
S3 terminal function
P05.06
selection
S4 terminal function
P05.07
selection
Terminal description:
Setting value
0
1
2
3
4
5
Detailed parameter description
0x0~0xF
BIT2
S3
Detailed parameter description
0.000~1.000s
Detailed parameter description
0: No function
1: Run
2: Fault reset
3: External fault
4: Reserved
5: Run enabling
6: Reserved
7~12: Reserved
13: Total electricity consumption
cleared
14: Accumulative power maintain
15: Reserved
Function
PWM rectifier does not act even though there is signal.
No function Set the unused terminal as non-function to avoid
misaction.
Run Control the operation through external terminals.
External fault reset, same as the function of STOP/RST.
Fault reset
Remote fault reset is available by the function.
PWM rectifier reports fault and stops when external fault
External fault signal is sent to the rectifier. The main contactor does
not switch off and the diode rectifier works normally.
Reserved
Run enabling PWM rectifier works after the enabling terminal is valid.
-26-
Goodrive3000 series PWM rectifier
Setting range
0x0~0xF
BIT1
S2
Setting range
0.000~1.000
Setting range
0~15
Description
Default
0x0
BIT0
S1
Default
0.000s
Default
1
2
0
0
