INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 51

Goodrive3000 series medium voltage inverters
Function
Name
code
setting
Voltage loop
P03.11 proportional
coefficient 1
Voltage loop
P03.12
integral coefficient 1
Voltage loop
P03.13 proportional
coefficient 2
Voltage loop
P03.14
integral coefficient 2
Switching voltage
P03.15
of PI parameters
Bus voltage filter
P03.16
coefficient
Current loop
P03.17 proportional
coefficient P
Current loop
P03.18 integral coefficient
I
Power factor
P03.19
setting
Rectification
P03.20
power factor angle
Feedback power
P03.21
factor angle
P03.22 Reserved
P03.23 Reserved
P05 Group Input terminals
P05.00 Reserved
Polarity selection
P05.01 of digital input
terminals
P05.02 Reserved
P05.03 Digital input
Detailed parameter
description
the rectifier)
0.001~30.000
0.01~300.00
0.001~30.000
0.01~300.00
0.01~30.00V
0~1.000s
0.001~30.000
0.01~300.00
0: Angle setting
1: Reserved
-90.0° ~90.0°
The positive means inductive
and the negative means
capacitive.
-90.0° ~90.0°
The positive means inductive
and the negative means
capacitive.
0x0~0xF
0 stands for positive polarity
BIT0: S1
BIT1: S2
BIT2: S3
BIT3: S4
0.000~1.000s
-50-
Goodrive3000 series PWM rectifier
Setting
Default Modify No.
range
0.001~30.000 2.000
0.01~300.00 20.00
0.001~30.000 5.500
0.01~300.00 10.00
0.01~30.00 10.00V
0~1.000s 0.000s
0.001~30.000 1.000
0.01~300.00 1.00
0~1 0
-90.0~90.0° 0.0°
-90.0~90.0° 0.0°
0x0~0xF 0x0
0.000~1.000 0.000s
○
37.
○
38.
○
39.
○
40.
○
41.
○
42.
○
43.
○
44.
◎
45.
○
46.
○
47.
●
48.
●
49.
●
50.
◎
51.
●
52.
○
53.
