Goodrive3000 series medium voltage inverters
Function
Name
code
Asynchronous
P12.03 motor 2 rated
speed
Asynchronous
P12.04 motor 2 rated
voltage
Asynchronous
P12.05 motor 2 rated
current
Asynchronous
P12.06 motor 2 stator
resistor
Asynchronous
P12.07 motor 2 rotor
resistor
Asynchronous
P12.08 motor 2 leakage
inductance
Asynchronous
P12.09 motor 2 mutual
inductance
Asynchronous
P12.10 motor 2
non-load current
Magnetic
saturation
P12.11 coefficient 1 for
the iron core of
AM 2
Magnetic
saturation
P12.12 coefficient 2 for
the iron core of
AM 2
Magnetic
saturation
P12.13 coefficient 3 for
the iron core of
AM 2
Magnetic
saturation
P12.14
coefficient 4 for
the iron core of
Detailed instruction of parameters
1~36000rpm
0~4000V
0.8~6000.0A
0.001~65.535Ω
0.001~65.535Ω
0.1~6553.5mH
0.1~6553.5mH
0.1~6553.5A
0.0~100.0%
0.0~100.0%
0.0~100.0%
0.0~100.0%
-188-
Goodrive3000 series converter
Default
Setting range
value
Depend
1~36000 on
model
Depend
0~4000 on
model
Depend
0.8~6000.0 on
model
Depend
0.001~65.535 on
model
Depend
0.001~65.535 on
model
Depend
0.1~6553.5 on
model
Depend
0.1~6553.5 on
model
Depend
0.1~6553.5 on
model
0.0~100.0 80.0%
0.0~100.0 68.0%
0.0~100.0 57.0%
0.0~100.0 40.0%
Modify No.
◎
421.
◎
422.
◎
423.
○
424.
○
425.
○
426.
○
427.
○
428.
◎
429.
◎
430.
◎
431.
◎
432.
