Goodrive3000 series medium voltage inverters
Chapter 6 Goodrive3000 series
Note: Chapter 6 is for the converter of two-quadrant and four-quadrant products.

6.1 Detailed function codes

P00 Group Basic function
Function
Name
code
P00.00 Speed control mode
1: Sensorless vector control mode 1 (apply to AM)
No need to install encoders. It is suitable in cases with high speed control accuracy for accurate speed
and torque control at all power ratings.
2: V/F control
No need to install encoders. It can improve the control accuracy with the advantages of stable operation,
valid low-frequency torque boost and current vibration suppression and the functions of slip
compensation and voltage adjustment. For detailed settings, refer to P04 group.
3: Close loop vector control mode (apply to AM and SM)
Need to install encoders. It is suitable in cases with high speed control accuracy for accurate speed and
torque control at all power ratings.
Function
Name
code
Run command
P00.01
channel
Select the run command channel of the inverter.
The control command of the inverter includes: start-up, stop, forward, reverse, jogging and fault reset.
0: Keypad running command channel("LOCAL/REMOT" light off)
Carry out the command control by RUN, STOP/RST on the keypad.
Press RUN and STOP/RST simultaneously in running state to make the inverter coast to stop.
1: Terminal running command channel ("LOCAL/REMOT" flickering)
Carry out the running command control by the forward rotation, reverse rotation and forward jogging and
reverse jogging of the multi-function terminals
converter
Detailed parameter description
0: Reserved
1: Sensorless vector control mode 1
(apply to AM)
2: V/F control
3: Close loop vector control mode
(apply to AM and SM)
Note: AM-Asynchronous motor
SM-Synchronous motor
Detailed parameter description
0: Keypad running command (LED
off)
1: Terminal running command
channel (LED flickering)
2: Communication running command
channel (LED on)
-62-
Goodrive3000 series converter
Setting range Default
0~3
Setting range Default
0~2
2
0
