Goodrive3000 series medium voltage inverters

Chapter 3 Installation guidelines

3.1 Unpacking inspection

1 Package inspections
Please check the package carefully, if there is any damage or opening, flooding or damp, contact with the
local supplier or our company as soon as possible.
2 Unpacking inspections
Please check as follows after unpacking:
Ensure there is no any component loss, the operation manual, keypad and other accessories are kept
well and there is only air bag in the package. If any problem, contact with the local supplier or our
company as soon as possible.

3.2 Requirements for Goodrive3000 application

3.2.1 Requirements for storage environment
(1) The temporary storage environment must meet the requirements in the table below
Table 3-1 Requirements for temporary storage environment
Items
Storage temperature
Transport temperature
Relative humidity
Atmosphere
(2) Requirements for permanent storage environment
If the inverter cannot be used at the moment due to change of project or other reasons after it is bought,
please store it by referring to the following instructions according to the specific situations.
The environment requirements for temporary storage must be met first of all. If the storage period
exceeds 3 months, the environment temperature must be controlled below 30℃. This is mainly because
the performances of the electrolytic capacitor inside the inverter will degrade if it is not powered.
Store the inverter with care to avoid intrusion of moisture. You can consider putting desiccant in the
packing box of the inverter to control the humidity inside the box below 70%.
If the inverter is installed inside a control cabinet or other equipment, especially on a construction site, it
will be in a moist and dusty condition. If it will not be used for a long period, we suggest you to remove it
and store in a place with a good environment.
The performances of the electrolytic capacitor will degrade if not used for a long period. When it is stored
long-term, we suggest you to electrify it at least once every year.
3.2.2 Requirements for operation environment
Items
Environment -10℃~50℃, derate 3% for every additional 1℃ when the temperature is above
-40℃~70℃
-10℃~50℃
5~95%, even if the humidity meets the
requirement, the situations which can
cause condensation and icing due to
sudden temperature change cannot
yet meet the requirement
The inverter should be stored in a place free of dust, direct sunshine,
flammable gasses, oil pollution, steam and vibration
Table 3-2 Requirements for operation environment
-11-
Specifications
It is required to avoid
condensation
caused by sudden change
of temperature
Specifications
Installation guidelines
and icing
