INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 37

Goodrive3000 series medium voltage inverters
Function
Name
code
Output terminal state
P10.07
at current fault
Record the output terminal state when fault occurs.
Function
Name
code
DC bus voltage at
P10.08
current fault
Record the DC bus voltage when fault occurs.
Function
Name
code
Grid voltage at
P10.09
current fault
Record the grid voltage when fault occurs.
Function
Name
code
Input current at
P10.10
current fault
Record the input current when fault occurs.
Function
Name
code
IGBT temperature at
P10.13
current fault
Record the IGBT temperature when fault occurs and display 3PH IGBT temperature at no fault.
Function
Name
code
Input terminal state
P10.22
at previous fault
Output terminal state
P10.23
at previous fault
DC bus voltage at
P10.24
previous fault
Grid voltage at
P10.25
previous fault
Input current at
P10.26
previous fault
IGBT temperature at
P10.29
previous fault
Record the IGBT temperature when fault occurs and display 3PH IGBT temperature at no fault.
Record the parameters at previous fault. For details, refer to P10.22~P10.29.
Function
Name
code
Input terminal state
P10.38
at previous 2 fault
Detailed parameter description
0x0~0xF
Detailed parameter description
0.0~6000.0V
Detailed parameter description
0.0~4000.0V
Detailed parameter description
0.0~6000.0A
Detailed parameter description
-20.0~120.0℃
Detailed parameter description
0x0~0xF
0x0~0xF
0.0~6000.0V
0.0~4000.0V
0.0~6000.0A
-20.0~120.0℃
Detailed parameter description
0x0~0xF
-36-
Goodrive3000 series PWM rectifier
Setting range
0x0~0xF
Setting range
0.0~6000.0V
Setting range
0.0~4000.0V
Setting range
0.0~6000.0A
Setting range
-20.0~120.0℃
Setting range
0x0~0xF
0x0~0xF
0.0~6000.0V
0.0~4000.0V
0.0~6000.0A
-20.0~120.0℃
Setting range
0x0~0xF
Default
0x0
Default
0.0V
Default
0.0V
Default
0.0A
Default
0.0℃
Default
0x0
0x0
0.0V
0.0V
0.0A
0.0℃
Default
0x0
