Goodrive3000 series medium voltage inverters
Function
Name
code
The parameters are used to set the corresponding functions of digital multi-functional input terminals.
Note: Two different multi-functional input terminals cannot be set to the same function.
Set value Function
0 No function
Forward rotation
1
operation (FWD)
Reverse rotation
2
operation (REV)
3-wire control
3
operation (Sln)
Forward rotation
4
jogging
Reverse rotation
5
jogging
6 Coast to stop
7 Fault reset
8 Operation pause
9 External fault input
Detailed instruction of parameters
32: Reserved
33: Cancel the frequency change
setting temporarily
34: DC brake
35: Shift motor 1 to motor 2
36: Shift the command to the keypad
37: Shift the command to the
terminals
38: Shift the command to the
communication
39: Pre-exciting command
40: Consumption power clear
41: Consumption power holding
42: External fault input 2
43~63: Reserved
The inverter will not work even when there are signals to input. The
terminals out of use may be set with no function in case of
malfunction.
Both the forward rotation and reverse rotation of the inverter are
controlled by external terminals.
The terminal is used to ensure the running mode of the inverter is
3-wire control. See specific information in the description of 3-wire
control mode in P05.12.
As for the frequency and ACC/DEC time at jogging, refer to the
detailed descriptions in P08.06, P08.07 and P08.08.
The inverter blocks the output, so the motor is out of control of the
inverter during stopping. The way is usually applied to large load
and no stop time limit. The definition is the same with that in P01.08
and the function is applicable to remote control.
External fault reset function is the same with the function of
STOP/RST on the keypad and it can realize remote fault reset.
The inverter slows down to stop but all running parameters are in
memory state, such as PLC parameters, traverse parameters and
PID parameters. When the signals disappear, the inverter will
restore to the state before stopping.
After the external fault signal is sent to the inverter, the inverter will
-87-
Goodrive3000 series converter
Setting range
Instruction
Default
value
