INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 107

Goodrive3000 series medium voltage inverters
Function
Name
code
Rectifier bridge
P07.11
module temperature
Converter module
P07.12
temperature
Software version of
P07.13
control board
Local accumulative
P07.14
running time
The parameters above can be read but cannot be modified.
Function
Name
code
High bit of power
P07.15
consumption
Low bit of power
P07.16
consumption
Display the power consumption of the inverter.
The power consumption of the inverter=P07.15*1000+P07.16
Function
Name
code
P07.18 Inverter rated power 0.4~3000.0kW
Inverter rated
P07.19
voltage
Inverter rated
P07.20
current
P07.21 Factory bar code 1 0x0000~0xFFFF
P07.22 Factory bar code 2 0x0000~0xFFFF
P07.23 Factory bar code 3 0x0000~0xFFFF
P07.24 Factory bar code 4 0x0000~0xFFFF
P07.25 Factory bar code 5 0x0000~0xFFFF
P07.26 Factory bar code 6 0x0000~0xFFFF
The parameters above can be read but cannot be modified.
Function
Name
code
P07.27 Current fault type
P07.28 Previous fault type
Previous 2 fault type
P07.29
Previous 3 fault type
P07.30
Previous 4 fault type
P07.31
Previous 5 fault type
P07.32
Detailed instruction of parameters
0.0~100.0℃
0.0~100.0℃
1.00~655.35
0~65535h
Detailed instruction of parameters
0~65535° (*1000)
0.0~999.9°
Detailed instruction of parameters
0~4000V
0.1~6000.0A
Detailed parameter description
0:No fault
1:IGBT U phase protection(OUt1)
2:IGBT V phase protection(OUt2)
3:IGBT W phase protection(OUt3)
4:OC1
5:OC2
6:OC3
7:OV1
8:OV2
-106-
Goodrive3000 series converter
Default
Setting range
value
Default
Setting range
value
Default
Setting range
value
Setting range Default
