INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 158

Goodrive3000 series medium voltage inverters
Function
Name
code
frequency
Braking current
P01.03
before start-up
Braking time
P01.04
before start-up
P01.05 ACC/DEC type
S curve
P01.06 beginning
proportion
S curve end
P01.07
proportion
P01.08 Stop mode
Starting
P01.09 frequency of DC
braking
Waiting time
P01.10 before DC
braking
DC braking
P01.11
current
P01.12 DC braking time 0.0~50.0s
Dead time of
P01.13 FWD/REV
rotation
Shifting between
P01.14 FWD/REV
rotation
P01.15 Stop speed
Detection of stop
P01.16
speed
Detection time of
P01.17
feedback speed
Terminal running
P01.18 protection when
power on
The running
P01.19
frequency is
Detailed instruction of parameters
0.0~100.0% (Inverter rated current)
0.0~50.0s
0: Linear type
1: S curve type
0.0~50.0% (ACC/DEC time)
0.0~50.0% (ACC/DEC time)
0: Decelerate to stop
1: Coast to stop
0.00~P00.03 (Max. frequency)
0.0~50.0s
0.0~100.0% (Motor rated current)
0.0~3600.0s
0: Switch after 0 frequency
1: Switch after starting frequency
2: Switch after delay at stop speed
(Reserved)
0.00~100.00Hz
0: Speed set value (delay without
stopping)
1: Speed detecting value (only valid
under vector control)
0.0~100.0s (only valid for P01.16=1)
0: Terminal running command is
invalid when power on
1: Terminal running command is valid
when power on
0: Run at the lower-limit frequency
1: Stop
-157-
Goodrive3000 series converter
Default
Setting range
value
0.0~100.0 0.0%
0.00~50.00 0.00s
0~1 0
0.0~50.0 30.0%
0.0~50.0 30.0%
0~1 0
0.00~P00.03 0.00Hz
0.0~50.0 0.0s
0.0~100.0 0.0%
0.0~50.0 0.0s
0.0~3600.0 0.0s
0~2 0
0.00~100.00 0.50 Hz
0~1 1
0.00~100.00 0.50s
0~1 0
0~2 0
Modify No.
◎
22.
◎
23.
◎
24.
◎
25.
◎
26.
○
27.
○
28.
○
29.
○
30.
○
31.
○
32.
◎
33.
◎
34.
◎
35.
◎
36.
○
37.
◎
38.
