Goodrive3000 series medium voltage inverters
Set value Function
pre-alarm
30 Reserved
Function
Name
code
Polarity of output
P06.06
terminals
The function code is used to set the polarity of the output terminals.
Set the bit to 0, the output terminal is positive. Set the bit to 1, the output terminal is negative.
BIT5 BIT4
RO4 RO3
Function
Name
code
Y switching-on delay
P06.07
time
Y switching-off delay
P06.08
time
HDO switching-on
P06.09
delay time
HDO switching-off
P06.10
delay time
Relay RO1
P06.11 switching-on delay
time
Relay RO1
P06.12 switching-off delay
time
Relay RO2
P06.13 switching-on delay
time
Relay RO2
P06.14 switching-off delay
time
Relay RO3
P06.15 switching-on delay
time
Relay RO3
P06.16 switching-off delay
time
The function code defines the corresponding delay time of the electrical level variation of programmable
output terminals from switching-on to switching-off.
than the set pre-alarm temperature and less than motor overheat
protection point.
Detailed instruction of parameters
00~1F
BIT3 BIT2
RO2 RO1
Detailed instruction of parameters
0.000~50.000s
0.000~50.000s
0.000~50.000s (only valid when
P06.00=1)
0.000~50.000s (only valid when
P06.00=1)
0.000~50.000s
0.000~50.000s
0.000~50.000s
0.000~50.000s
0.000~50.000s
0.000~50.000s
-98-
Goodrive3000 series converter
Instruction
Setting range
00~1F
BIT1
Y1
Setting range
0.000~50.000
0.000~50.000
0.000~50.000
0.000~50.000
0.000~50.000
0.000~50.000
0.000~50.000
0.000~50.000
0.00~50.00
0.00~50.00
Default
value
00
BIT0
HDO
Default
value
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
