INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 192

Goodrive3000 series medium voltage inverters
Function
Name
code
PZD2 sending 0: Invalid
P15.13
P15.14 PZD3 sending
P15.15 PZD4 sending
P15.16 PZD5 sending
P15.17 PZD6 sending
P15.18 PZD7 sending
P15.19 PZD8 sending
P15.20 PZD9 sending
P15.21 PZD10 sending
P15.22 PZD11 sending
P15.23 PZD12 sending
Temporary
P15.24 variable 1 for
PZD sending
Fault time of DP
P15.25 communication
overtime
Fault time of
CANopen
P15.26
communication
timeout
CANopen baud
P15.27
rate
CAN
P15.28 communication
address
P15.29 CAN baud rate
Detailed instruction of parameters
1: Running frequency
2: Set frequency
3: Bus voltage
4: Output voltage
5: Output current
6: Output torque actual value
7: Output power actual value
8: Running rotating speed
9: Running linear speed
10: Ramp reference frequency
11: Fault code
12: AI1 value
13: AI2 value
14: AI3 value
15: PULSE frequency
16: Input state of terminals
17: Output state of terminals
18: PID reference
19: PID feedback
20: Motor rated torque
0~65535
0.0: Invalid
0.1~60.0s
0.0 (invalid)
0.1~60.0s
0: 1000k
1: 800k
2: 500k
3: 250k
4: 125k
5: 100k
6: 50k
7: 20k
0~127, 0 is broadcast communication
address
0: 1000k
1: 500k
2: 250k
3: 125k
-191-
Goodrive3000 series converter
Default
Setting range
value
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~65535 0
0.0~60.0 0.0s
0.0~60.0 0.0s
0~7 0
0~127 1
0~4 1
Modify No.
○
470.
○
471.
○
472.
○
473.
○
474.
○
475.
○
476.
○
477.
○
478.
○
479.
○
480.
○
481.
○
482.
○
483.
◎
484.
◎
485.
486.
