Goodrive3000 series medium voltage inverters
Terminal
Type
No.
Analog output AO3
S7
S8
Switch
HDI
input/output
HDO
RO3A
RO3B
Relay output
RO3C
CANL
CAN
CANH
communication
COMX
Motor PTA
temperature PTB
detection PTC
Note: Use the DIP switch to connect the termination resistor for CAN communication. When
connecting the termination resistor, the DIP switch is switched to ON (11); when not, the switch is
switched to OFF (00).
9.1.1.2 Wiring of comprehensive extension PG card
Terminal
name
GND as reference;
Analog output 1. Output range: -10V~10V/-20mA~20mA, error ± 1%,
1 25℃
2. Voltage or current input is set by J14
COM as reference;
Switch input 7
1. Internal impedance: 3.3kΩ
2. The terminal is the dual-direction input terminal
Switch input 8
supporting both NPN and PNP
3. 12~30V voltage input is available
High speed
4. Max. input frequency: 1kHz
pulse input
5. HDI is high speed pulse input, input Max. frequency:
50kHz
CME as reference;
High speed
1. Output voltage amplitude: 24V
pulse output
2. Output frequency: 50kHz
Relay 3 NO
contact
Relay 3 NC
1. Contact capacity: AC250V/3A, DC30V/1A
contact
2. Cannot be high-frequency switch output (caution)
Relay 3
common
contact
CAN
CAN communication used in master-slave control
communication
Analog input PT100/PT1000 detection
