INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 188

Goodrive3000 series medium voltage inverters
Function
Name
code
Detection level
P11.09 of overload
pre-alarm
Detection time of
P11.10 overload
pre-alarm
Detection level
P11.11 of underload
pre-alarm
Detection time of
P11.12 underload
pre-alarm
Output terminal
action during
P11.13
undervoltage
and auto-reset
Detection value
P11.14 of speed
deviation
Detection time of
P11.15
speed deviation
Automatic
frequency-decre
P11.16
asing at voltage
drop
P12 Group Motor 2 parameters
P12.00 Motor 2 type
Asynchronous
P12.01 motor 2 rated
power
Asynchronous
P12.02 motor 2 rated
frequency
Detailed instruction of parameters
after underload fault
3: Inverter stops running after
underload and overload alarm
LED hundreds:
0: Detect all the time
1: Detect in constant running
P11.11~200%
0.1~60.0s
0%~P11.09
0.1~60.0s
0x00~0x11
LED ones:
0: Action at undervoltage
1: No action at undervoltage
LED tens:
0: Action during auto-reset
1: No action during auto-reset
0.0~50.0%
0.0~10.0s (No speed deviation
protection at 0.0)
0:Invalid
1:Valid
0: Asynchronous motor
1: Reserved
0.1~3000.0kW
0.01Hz~P00.03 (Max. frequency)
-187-
Goodrive3000 series converter
Default
Setting range
value
P11.11~200 150%
0.1~60.0 1.0s
0~P11.09 50%
0.1~60.0 1.0s
00~11 0x00
0.0~50.0 10.0%
0.0~10.0 0.5s
0~1 0
0~1 0
Depend
0.1~3000.0 on
model
0.01~P00.03 50.00Hz
Modify No.
○
410.
○
411.
○
412.
○
413.
○
414.
○
415.
○
416.
○
417.
◎
418.
◎
419.
◎
420.
