INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 197

Goodrive3000 series medium voltage inverters
Function
Name
code
Speed ratio
P20.06 between motor
and encoder
P20.07 Reserved
P20.08 Reserved
P20.09 Reserved
Magnetic pole
P20.10
initial angle
Magnetic pole
P20.11 initial angle
autotuning
Reserved
P20.12
variable
Reserved
P20.13
variable
Reserved
P20.14
variable
P21 Group Master-slave control
Master-slave
P21.00
control mode
Master-slave
P21.01 communication
data
Master-slave
P21.02
control mode
Slave reference
P21.03
signal gain
Reserved
P21.04
variable
Reserved
P21.05
variable
Reserved
P21.06
variable
Reserved
P21.07
variable
Reserved
P21.08
variable
Reserved
P21.09
variable
Detailed instruction of parameters
0.000~65.535
0.00~359.99
0~2
0: No operation
1: Rotation autotuning
2: Static autotuning (suitable for rotary
encoder feedback)
0~65535
0~65535
0~65535
0: Invalid
1: The local is the master
2: The local is the slave
0: CAN
1: RS485
0: Master-slave mode 0
1: Master-slave mode 1
0.0~500.0%
0~65535
0~65535
0~65535
0~65535
0~65535
0~65535
-196-
Goodrive3000 series converter
Default
Setting range
value
0.000~65.535 1.000
0.00~359.99 0
0~2 0
0~65535 0
0~65535 0
0~65535 0
0~2 0
0~1 0
0~1 0
0.0~500.0 100.0%
0~65535 0
0~65535 0
0~65535 0
0~65535 0
0~65535 0
0~65535 0
Modify No.
○
579.
○
580.
○
581.
○
582.
○
583.
◎
584.
○
585.
○
586.
○
587.
◎
588.
◎
589.
◎
590.
○
591.
●
592.
●
593.
●
594.
●
595.
●
596.
●
597.
