INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 191

Goodrive3000 series medium voltage inverters
Function
Name
code
Communication
P14.03
response delay
Fault time of
P14.04 communication
timeout
Transmission
P14.05
fault processing
Communication
P14.06 processing
action
P14.07 Reserved
P14.08 Reserved
P15 Group PROFIBUS function
P15.00 Module type
PROFIBUS/CA
P15.01 Nopen
module address
PZD2 receiving 0: Invalid
P15.02
P15.03 PZD3 receiving
P15.04 PZD4 receiving
P15.05 PZD5 receiving
P15.06 PZD6 receiving
P15.07 PZD7 receiving
P15.08 PZD8 receiving
P15.09 PZD9 receiving
P15.10 PZD10 receiving
P15.11 PZD11 receiving
P15.12 PZD12 receiving
Detailed instruction of parameters
0~200ms
0.0 (invalid), 0.1~60.0s
0: Alarm and coast to stop
1: Continue to run without alarm
2: Stop according to stop way without
alarm (only in communication control
mode)
3: Stop according to stop way without
alarm (in all control modes)
LED ones:
0: With response to write operation
1: Without response to write operation
LED tens:
0: Communication encryption setting
is invalid
1: Communication encryption setting
is valid
0: PROFIBUS
0~127
1: Set frequency
2: PID reference
3: PID feedback
4: Torque set value
5: Set value of forward rotation
upper-limit frequency
6: Set value of reverse rotation
upper-limit frequency
7: Electromotion torque upper limit
8: Braking torque upper limit
9: Virtual input terminal command
10: Virtual output terminal command
11: Voltage set value (special for V/F
separation)
12: AO output set value 1
13: AO output set value 2
-190-
Goodrive3000 series converter
Default
Setting range
value
0~200 5
0.0~60.0 0.0s
0~3 0
0x00~0x11 0x00
0~1 0
0~127 2
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
0~20 0
Modify No.
○
451.
○
452.
○
453.
○
454.
●
455.
●
456.
◎
457.
◎
458.
459.
○
460.
○
461.
○
462.
○
463.
○
464.
○
465.
○
466.
○
467.
○
468.
○
469.
