INVT Goodrive3000 GD3000-01-055G-12 Operation Manual page 138

Goodrive3000 series medium voltage inverters
P17 Group State view 1
Function
Name
code
P17.00 Setting frequency
P17.01 Output frequency
Ramp reference
P17.02
frequency
P17.03 Output voltage
P17.04 Output current
P17.05 Motor speed
P17.06 Torque current
P17.07 Exciting current
P17.08 Motor power
P17.09 Output torque
Evaluated motor
P17.10
frequency
P17.11 DC bus voltage
Digital input
P17.12
terminals state
Digital output
P17.13
terminals state
Detailed parameter description
Display current set frequency of the
inverter
Range: 0.00Hz~P00.03
Display current output frequency of
the inverter
Range: 0.00Hz~P00.03
Display current ramp given
frequency of the inverter
Range: 0.00Hz~P00.03
Display current output voltage of the
inverter
Range: 0~4000V
Display current output current of the
inverter
Range: 0.0~3000.0A
Display the rotation speed of the
motor.
Range: 0~65535RPM
Display current torque current of the
inverter
Range: -3000.0~3000.0A
Display current exciting current of
the inverter
Range: -3000.0~3000.0A
Display current power of the motor.
Setting range: -300.0%~300.0%
(the rated current of the motor)
Display the current output torque of
the inverter.
Range: -250.0~250.0%
Evaluate the motor rotor frequency
on open loop vector
Range: 0.00~ P00.03
Display current DC bus voltage of
the inverter
Range: 0.0~6000.0V
Display current switch input
terminals state of the inverter
0000~00FF
Display current switch output
terminals state of the inverter
0000~000F
-137-
Goodrive3000 series converter
Setting range Default
0.00~P00.03 0.00Hz
0.00~P00.03 0.00Hz
0.00~P00.03 0.00Hz
0~4000
0.0~3000.0
0~65535 0 RPM
-3000.0~3000.0A
-3000.0~3000.0A
-300.0~300.0 0.0%
-250.0~250.0 0.0%
0.00~P00.03 0.00Hz
0.0~6000.0
0000~00FF
0000~000F
0V
0.0A
0.0A
0.0A
0V
0
0
