Goodrive3000 series medium voltage inverters
Set value Function
30 ACC/DEC prohibition
Cancel the
33 frequency change
setting temporarily
34 DC brake
Shift motor 1 to
35
motor 2
Shift the command to
36
the keypad
Shift the command to
37
the terminals
Shift the command to
38
the communication
Pre-exciting
39
command
Consumption power
40
clear
Consumption power
41
holding
42 External fault input 2
43~63 Reserved
Function
Name
code
Polarity of input
P05.10
terminals
The function code is used to set the polarity of the input terminals.
Set the bit to 0, the input terminal is anode.
Set the bit to 1, the input terminal is cathode.
BIT7 BIT6
S8 S7
Ensure there is no external signal impact on the inverter (Except
stop command) to keep current frequency output.
When the terminal switches on, the frequency set by UP/DOWN
can be cleared and all frequency references restore to the values
set by the channels. When the terminal switches off, the frequency
comes back the values after increasing or decreasing setting.
In the process of slowing down to stop, after the command
becomes valid, the inverter will decrease to P01.15 (stop speed)
and then begin DC braking immediately. The braking time is not
limited by P01.12 (DC braking time at stopping).
When the terminal is valid, motor 1 will shift into motor 2. When the
terminal is invalid, the running command returns to the original
state.
When the terminal is valid, the running command will compel to shift
to keypad running command. When the terminal is invalid, the
running command returns to the original state.
When the terminal is valid, the running command will compel to shift
to terminal running command. When the terminal is invalid, the
running command returns to the original state.
When the terminal is valid, the running command will compel to shift
to communication running command. When the terminal is invalid,
the running command returns to the original state.
Start pre-exciting command of the motor until the terminal becomes
invalid.
When the command is valid, the power of the inverter will be
cleared.
When the command is valid, the current running of the inverter will
not influence the power.
The inverter will alarm and stop after receiving the external fault
signal.
Detailed instruction of parameters
0x000~0x1FF
BIT5 BIT4
S6 S5
-89-
Goodrive3000 series converter
Instruction
Setting range
0x000~0x1FF
BIT3 BIT2
S4 S3
Default
value
0x000
BIT1 BIT0
S2 S1
