P05 Group Input terminals
Function
Name
code
P05.00 HDI input type
Set the HDI input type.
Function
Name
code
P05.01 S1 terminal function
P05.02 S2 terminal function
P05.03 S3 terminal function
P05.04 S4 terminal function
P05.05 S5 terminal function
P05.06 S6 terminal function
P05.07 S7 terminal function
P05.08 S8 terminal function
Detailed instruction of parameters
0: HDI is pulse input.
1: HDI is switch input.
Detailed instruction of parameters
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward rotation jogging
5: Reverse rotation jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting
(DOWN)
12: Cancel the frequency change
setting
13: Shift between A setting and B
setting
14: Shift between combination setting
and A setting
15: Shift between combination setting
and B setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Multi- step speed pause
21: ACC/DEC time option 1
22: ACC/DEC time option 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Reserved
27: Reserved
28: Reserved
29: Torque control prohibition
30: ACC/DEC prohibition
31: Reserved
-86-
Goodrive3000 series converter
Default
Setting range
value
0~1
Default
Setting range
value
0~63
0~63
0~63
0~63
0~63
0~63
0~63
0~63
0
0
0
0
0
0
0
0
0
