Tilt up the end of the motherboard that is near the front of the chassis.
c. Lift the motherboard out of the chassis (panel 3).
Ensure that the remaining cables do not get caught on edges of the motherboard.
14. Install a new motherboard.
See "Install the Motherboard" on page
Related Information
"Install the Motherboard" on page 151
■
"Verify the Motherboard" on page 158
■

Install the Motherboard

This is a cold-service procedure that must be performed by qualified service personnel. Power
down the server completely before performing this procedure.
Caution - This procedure requires that you handle components that are sensitive to ESD which
can cause server components to fail.
When replacing the motherboard, remove the SPM and SCC PROM from the old motherboard
and install these components on the new motherboard. The SPM contains the Oracle ILOM
system configuration data, and the SCC PROM contains the system host ID and MAC address.
Transferring these components preserves the system-specific information stored on these
modules. Whenever you replace the motherboard or the SPM, you must update the firmware so
the portions of firmware in the SPM and on the motherboard are consistent.
1. Take the necessary ESD precautions.
See "Prevent ESD Damage" on page
2. Grasp the motherboard by the handle and place it into the chassis.
Ensure that remaining cables do not get caught on edges of the motherboard.
Set the motherboard towards the front of the chassis, then slide it toward the rear of the chassis.
Tighten the captive screw (in the corner near the fans) that secures the
3.
motherboard to the chassis.
Reinsert and tighten the four bus bar screws that secure the motherboard to the
4.
power supply backplane.
151.
55.
Install the Motherboard
Servicing the Motherboard 151
