swEventTrapLevel
authTraps
There are six communities and respective trap recipients supported by the agent.
The first three communities are for read-write access (rw) and the last three are for
read-only access (ro). Note that the factory default value for the trap recipient of
each community is "0.0.0.0." The factory default values for the community strings
are:
Note that in order for an SNMP Management Station to receive a trap generated
by the agent, the administrator must configure a trap recipient value to correspond
to the IP address of the Management Station. In addition, for V4.1.x, the trap
recipient must be able to pass the Access Control List (ACL) check.
There are six ACLs to restrict SNMP get/set operations to hosts under a
host-subnet-area. Host-subnet-area is defined by comparing non-zero IP octets.
For example, an ACL of "192.168.64.x" enables access for any hosts that start
with the specified octets. The connecting host is enabled as "192.168.64.xx." All
Fabric OS Version 3.1.x/4.1.x Reference Guide
The event trap level in conjunction with the event's severity
level. When an event occurs and if its severity level is at or
below the set value, the SNMP trap, swEventTrap, is sent to
configured trap recipients. By default, this value is set at 0,
implying that no swEventTrap is sent. Possible values are:
0 - none
1 - critical
2 - error
3 - warning
4 - informational
5 - debug
When enabled, the authentication trap, authenticationFailure,
is transmitted to a configured trap recipient in the event the
agent received a protocol message that is not properly
authenticated. In the context of SNMPv1 and SNMPv2c, this
means that a request contains a community string that is not
known to the agent. The default value for this parameter is 0
(disabled).
Community 1: Secret Code
Community 2: OrigEquipMfr
Community 3: private
Community 4: public
Community 5: common
Community 6: FibreChannel
agtcfgSet
