Install a Fan Module

This procedure describes how to install a replacement fan module in the server.
For serviceability considerations, see
Before You Begin ■
For fan module designation information, see
■
For instructions on removing a fan, see
■
1. If you are installing a replacement fan module for one that has failed, check the
indicator of the failed fan slot to ensure the fault indicator is no longer lit.
This is necessary to ensure the indicator status is cleared before you insert the new fan. See
"Fan Module Reference" on page 135
2. Orient the fan module so the connector on the bottom of the module is aligned
with the connector on the inside of the slot and all keying and labeling are
correctly positioned.
"Component Serviceability" on page
"Component Designations" on page
"Remove a Fan Module" on page
for fan module indicator locations.
Install a Fan Module
70.
73.
130.
Servicing CRU Components 133
