EMBEDDED Intel486™ PROCESSOR HARDWARE REFERENCE MANUAL
Another placement technique is called orthogonal arrangement, which requires more area than
the previous technique but produces similar results. This arrangement is shown in
These techniques reduce the electromagnetic interference (EMI), which is discussed in
10.3.3.1, "Electromagnetic Interference (EMI)."
Return or
GND Trace
†
Typical values should range between .01 µF and .1 µF
10-6
V Trace
CC
GND
GND
GND
V
CC
Figure 10-3. Decoupling Capacitors
Figure
Section
GND
GND
GND
V
CC
10-3.
