OmniS/R-9P-48V Technical Specifications
Total Module Slots
Total Slots for Switching Modules
Physical Dimensions
Weight
Switching Backplane
Voltage Range
Current Draw
Watts (Output)
Current Provided
Temperature Operating Range
Humidity
Altitude
Heat Generation
Agency Listings
Omni Switch/Router Chassis and Power Supplies
9
8
24.50" (62.23 cm) high, 16.60" (42.16 cm) wide,
13.25" (36.66 cm) deep
96 lb. (43.55 kg), fully populated with modules and power
supplies.
Up to 22 Gbps (aggregate) switching fabric capacity
40-60 VDC
23 Amps
725
120 Amps at 5.15 VDC
6 Amps at 12 VDC
6 Amps at 3.3 VDC
8 Amps at 1.5 VDC
0 to 70 degrees Celsius
32 to 158 degrees Fahrenheit
5% to 90% Relative Humidity (Operating)
0% to 95% Relative Humidity (Storage)
Sea level to 10,000 feet (3 km)
2219 BTUs per hour (one power supply)
UL 1950; CSA-C22.2 #950-M90; TUV EN60950; CB
Certification IEC 950; FCC Title 47 CRF Part 15, Subpart B
(Class A & Class B); IEC EN55022, 1995 (Class A & Class B)
CISPR 22, 1995; IEC 1000-3-2; IEC 1000-3-3 (EN60555-2); IEC
1000-4-2 (EN61000-4-2, per EN50082-1, 1992); EN55024 IEC
1000-4-3 (EN61000-4-3, per EN50082-1, 1992); IEC 1000-4-4
(EN61000-4-4) Level 4; IEC 1000-4-5 (EN61000-4-5) Level 4;
IEC 1000-4-6 (EN61000-4-6); IEC 1000-4-8 (EN61000-4-8);
IEC 1000-4-11 (EN61000-4-11); ENV 50204: 1996.
Page 1-17
