OmniS/R-3 Chassis Technical Specifications
Total Module Slots
Total Slots for Switching Modules
Physical Dimensions
Weight
Switching Backplane
Voltage Range
Current Draw
Watts (Output)
Current Provided
Heat Generation
Temperature Operating Range
Humidity
Altitude
Agency Listings
Omni Switch/Router Chassis and Power Supplies
3
2
5.25" (13.34 cm) high, 17.13" (43.51 cm) wide,
13.00" (33.02 cm) deep
18 lb. (8.18 kg), fully populated with modules and power
supplies.
Up to 7 Gbps (aggregate) switching fabric capacity
85-270 VAC, 47 to 63 Hz, auto-ranging and auto-sensing
3.8 Amps at 100/115 VAC
1.7 Amps at 230 VAC
200
32.8 Amps at +5 Volts
3 Amps at +12 Volts
Approximately 1020 BTUs per hour
0 to 45 degrees Celsius
32 to 113 degrees Fahrenheit
5% to 90% Relative Humidity (Operating)
0% to 95% Relative Humidity (Storage)
Sea level to 10,000 feet (3 km)
UL 1950
CSA-C22.2
EN60950
FCC Part 15, Subpart B (Class A)
EN55022, 1987/EN50081
FCC Class B
C.I.S.P.R. 22: 1985
EN50082-1, 1992
IEC 801-2, 1991
IEC 801-3, 1984
IEC 801-4, 1988
VCCI V-3/94.04 (Class A & Class B)
EN 61000-4-2: 1995
EN 61000-4-3: 1995
EN 61000-4-4: 1995
EN 61000-4-5: 1995
EN 61000-4-6: 1996
EN 61000-4-8: 1993
EN 61000-4-11: 1994
ENV 50204: 1996
Page 1-9
