Appendix C — Specifications
TS11xx Technology Barcode Element Specifications
For the official IBM barcode label specification, see https://www.ibm.com/
support/pages/node/651747. Unless otherwise specified, tolerances are
X.XXX ± 0.127 mm, X.XX ± 0.76 mm.
 Minimum symbol height is 7.1 mm, measured to the inside of the label's
 The wide‐to‐narrow ratio is 2.75.
 The narrow element width is 0.500 mm + 0.03/‐ 0.07 mm.
 The nominal width of the wide spaces and bars is 1.375 mm.
 The inter‐character gap is 0.500 mm + 0.03/‐ 0.07 mm.
 The minimum quiet zone at the beginning and end of a printed barcode
 The total nominal barcode string length (including quiet zones) is
 The edge of the barcode is the edge of the printed area attached to the
 Variation between all bars, white and black, must be less than
TS11xx Technology Physical Label Specifications
 Label stock must fit within the label recess on the face of the cartridge
 Minimum length sufficient for the quiet zones, start‐stop, and data
 Minimum width no less than 1.5 mm narrower than the cartridge label
 Maximum label thickness, including the RFID tag, if present, together
 The label and adhesive must have an environmental performance to
November 2020
edge.
string is 5.0 mm (10 times the narrow element width).
85.75 mm.
bar. The edge roughness is the transition encountered as a horizontal
line is moved vertically from all black to all white. The edge roughness
maximum is 0.04 mm.
±0.04 mm.
without curling up on the sides or ends (88.5 mm X 11.9 mm +0/–0.4).
characters (nominal 85.75 mm).
recess width. Corners are cut with a 1.5 mm radius.
with any associated layers and adhesives cannot exceed 0.75 mm.
match or exceed the environmental specifications of the cartridge to
which it is applied.
