Appendix C — Specifications
Supply-End Connector Types
The supply‐end connector on the cord depends on the country where the
library will be installed. The following table shows the supply‐end
connector types used in each country.
Part Country of Use
Number
9594 North America,
Korea
7029 North America,
Korea
6807 Japan
8665 United Kingdom,
Continental
Europe
Grounding Requirements
Due to electromagnetic interference (EMI) filtering in each dual AC power
module, the leakage current for main frames and drive frames is such that
they require a secure connection from the chassis of the unit to an earth
ground.
Use one or more of the following methods for securing a ground
connection when installing a main frame or drive frame:
 Add cord lock brackets (Spectra Logic part number 5497) to all main
 Use a cord with locking connectors at both ends, such as L6‐20P to
November 2020
Plug Style
NEMA L6‐20P
NEMA L6‐30P
NEMA L6‐20P
IEC 60309
 Cord lock brackets and cords with locking connectors are not
Notes:
compatible and cannot be used simultaneously.
 Expansion Frame Power Modules do not require locking
cords or special grounding.
and drive frames. See Installing Cord Locks on page 461 for more
information.
locking C19 (Spectra Logic part number 9594).
Length Appearance
14.8 ft (4.5 m)
14.8 ft (4.5 m)
13.9 ft (4.24 m)
15 ft (4.6 m)
User Guide—Spectra TFinity Library
Power Specifications
