Chapter 12 — Library Troubleshooting

Reset the Power Control Module

The main frame and each drive expansion frame has a PCM. To reset the
over‐current circuit that protects the power system in the event of a voltage
surge, insert the tip of a toothpick or other similar non‐conductive object
into the hole on the back of the PCM to press the reset button.
Do not use a metallic object to press the reset button. You may inadvertently cause
Caution
an electrical short inside the module.
Figure 233 Power Control Module reset button.

Reset the LCM or RCM

To reset the LCM or RCM insert the tip of a toothpick or other similar non‐
conductive object into the hole on the back of the LCM or RCM to press the
reset button.
Do not use a metallic object to press the reset button. You may inadvertently cause
Caution
an electrical short inside the module.
Resetting the RCM resets the motion control for the TeraPorter(s). Any move
Important
requests will fail until the RCM completes its initialization.
Resetting the LCM resets the front panel and the web server. Any connections to
Important
the library through the BlueScale web interface are lost. Wait five minutes for the
reset to complete and then reconnect. Backup operations are not affected.
Figure 234 The reset button on the Spectra LS (LCM or RCM).
November 2020
Reset
User Guide—Spectra TFinity Library
Reset the Power Control Module
Power Control
Module (PCM)
Reset
button
