Appendix C — Specifications
The following table shows the fully loaded maximum weight of each frame
type.
a. 6D0T means six Drive Bay Assemblies and zero TeraPack Bay Assemblies. 3D3T means three Drive Bay

Service Access Requirements

Minimum Access Requirements A minimum of 2 ft (0.6 m) of clearance is
required on the left and right ends of the library to provide service access
to the library. If data center equipment is on rolling racks and can be easily
moved to provide 2 ft (0.6 m) of clearance on each end of the library, then
having equipment adjacent to the ends of the library is acceptable. In
addition, a minimum of 2 ft (0.6 m) of clearance at the front and back of the
main frame, each drive expansion frame, and each service or bulk TAP
service frame is required for airflow and service and operator access.
Recommended Access Requirements
Providing 3 feet (0.9 meters) of clearance on each side of the library is highly
Important
recommended.
Refer to the Spectra TFinity Library Site Preparation Guide for detailed
information about space and access requirements.
November 2020
a
Frame Type
6D0T Main Frame
3D3T Main Frame
6D0T Drive Frame
3D3T Drive Frame
Media Frame
Service Frame
Bulk TAP Service
Frame
Assemblies and three TeraPack Bay Assemblies or shelves.
Maximum Weight for LTO
Frame
1574 lb (714 kg)
1461 lb (663 kg)
1561 lb (708 kg)
1447 lb (656 kg)
1227 lb (557 kg)
1000 lb (454 kg)
1087 lb (493 kg)
User Guide—Spectra TFinity Library
Service Access Requirements
Maximum Weight for
TS11xx Technology Frame
1641 lb (744 kg)
1578 lb (716 kg)
1627 lb (738 kg)
1569 lb (712 kg)
1180 lb (535 kg)
980 lb (445 kg)
1067 lb (484 kg)
532
