Appendix C — Specifications
Cleaning Cartridges
Cleaning cartridges are valid for 50 uses. Do not rewind and reuse the
material in a cleaning cartridge. Reusing the material may redistribute
contaminants previously removed from the tape path. If all of the cleaning
material has been used, discard the cartridge and use a new cleaning
cartridge.

Barcode Label Specifications

Symbology The barcode labeling scheme used on Spectra Logic certified
media uses the barcode symbology of USS‐39. You can obtain a complete
description and definition of this symbology from the Automatic
Identification Manufacturers (AIM) specification, the Uniform Symbol
Specification (USS‐39), and the ANSI MH10.8M‐1993 ANSI Barcode
specification.
Application and Orientation The barcode label must be applied to the
cartridge so that it fits within the label recess on the edge of the cartridge
without curling up on the sides or ends. The label must be oriented so that the
barcode characters are along the edge closest to the hub side of the cartridge.
Printed Characters The label can have human‐readable alphanumeric
characters printed along the top or bottom edge of the label provided there
is no conflict or interference with the automation code. This text must
include the barcode data, but can also include additional text. The format
and colors of the human readable characters is up to the customer and
label vendor. For location restrictions, see Detailed Specifications for LTO
Cartridge Barcodes on page 554 and Detailed Specifications for TS11xx
Technology Cartridge Barcodes on page 555.
November 2020
Note: When using barcode labels with alphanumeric characters along
the bottom edge, the label must be positioned so that barcode is
at least 13.72 mm below the top edge of the cartridge to ensure
that the barcode reader can read the label.
