Chapter 5 — Operating the Library

Use the BlueScale Vision Camera

The BlueScale Vision camera and web‐based viewer let you see the interior
of the library to observe import and export operations, tape mounts,
cartridge moves, and robotic operations in real time.
Use the following steps to launch the BlueScale Vision viewer.
1. Connect an Ethernet cable from the BlueScale Vision camera connector
2. Connect to the BlueScale Vision viewer.
November 2020
on the back of the frame to an Ethernet network.
BlueScale Vision
camera connector
BlueScale Vision
camera connector
Figure 102 Location of the BlueScale Vision camera connector.
 Using the Camera Icon
a. Using a remote connection, log into the library's BlueScale web
interface using a web browser.
Note: The software included with the black camera requires
®
ActiveX to view the streaming video and controls. You
must use Internet Explorer or see Streaming video and
camera controls do not work for the library camera on
page 365 for alternate solutions.
Main Frame or Drive Expansion Frame
Media Expansion Frame
User Guide—Spectra TFinity Library
Use the BlueScale Vision Camera
173
