Spectra TFinity User Manual page 530

Appendix C — Specifications
Expansion Frames
The capacity of an expansion frame depends on the type of frame and its
configuration. For each expansion frame, add the frame's capacity to that
of the main frame to calculate the capacity of the entire library.
TS11xx Technology
TeraPack Magazines
Tape Drives
Drive Expansion Frame
1 ‐ 12 87 (783)
13 ‐ 24 75 (675)
Media Expansion Frame
0 110 (990)
Service Frame
The service frames are located at each end of the library. The capacity for
standard service frames and bulk TAP service frames is the same. Add the
capacity of each service frame to the capacity of the other frames to
calculate the capacity of the entire library.
Starting with BlusScale12.8.04, a non‐isolating service frame configuration is
available that replaces the right and left service frame with media expansion
frames. See
TS11xx Technology
TeraPack Magazines
Tape Drives
0 42 (378)
November 2020
LTO TeraPack
Tape Magazines
Drives (Slots)
Drive Expansion Frame
1 ‐ 12 101 (1010)
13 ‐ 24 89 (890)
Media Expansion Frame
0 130 (1300)
TS1140
(Slots) Technology
3132
2700
3960
Expansion Frames.
LTO TeraPack
Tape Magazines
Drives (Slots)
0 50 (500)
TS1140
(Slots) Technology
1512
Native Capacity (TB)
LTO-4 LTO-5 LTO-6
808 1515 2525
712 1335 2225
1040 1950 3250
Native Capacity (TB)
TS1150
Technology Technology
7830
6750
9900
Native Capacity (TB)
LTO-4 LTO-5 LTO-6
400 750 1250
Native Capacity (TB)
TS1150
Technology Technology
3780
User Guide—Spectra TFinity Library
Data Storage Capacity
LTO-7 Type M LTO-8
6060 9090 12120
5340 8010 10680
7800 11700 15600
TS1155 TS1160
Technology
11745 15660
10125 13500
14850 19800
LTO-7 Type M LTO-8
3000 4500 6000
TS1155 TS1160
Technology
5670 7560
530
